P7UC2024 - Aircraft wing geometry study in pSeven Enterprise

Download insert_drive_file

Authors:

George Biryukov, Application Engineer, pSeven SAS

Journal / Event:

pSeven User Conference 2024

Abstract:

This presentation will showcase the capabilities of pSeven Enterprise in automating complex engineering workflows, with a specific focus on analysing the aerodynamic characteristics of aircraft wings. The live demonstration will highlight key platform features, such as automated report generation, custom block development and workflow reference blocks, by applying a methodology that addresses two common tasks: optimizing wing geometry for enhanced aerodynamic performance and refining deformed wing geometry to improve external load distribution accuracy. Traditionally, these tasks involve repetitive manual calculations, including geometry preparation, simulation execution, and result extraction, all of which are time-consuming and subject to human error. By implementing workflows in pSeven Enterprise, we will show how these processes can be facilitated, allowing users to input the initial geometry file and validate the final results, thereby reducing complexity and minimizing the potential for error.

Keywords: P7UC2024, Aerospace, Aircraft design, Aerodynamics, pSeven Enterprise
